This installation reference covers 2014-2021 Jeep Grand Cherokee Multicolor DRL Boards. Match the product, vehicle configuration and controller part number before starting.
Part # F20, F21, F22, F23
Jeep Grand Cherokee Multicolor DRL Boards (2014-2021)
Install GuideStep 1:
Before starting the install, plug in your DRL boards and controller to test functionality. Confirm color changes, brightness, and Bluetooth control.
🔌 Use a 12V bench tester or your vehicle’s battery. Do not skip this step.
RGBWA version Wiring
Flow Version Wiring
Step 2: Remove your bumper to access headlights.
Step 3: Open your headlights using the cutting method.
The Jeep Grand Cherokee headlights are sealed and require cutting to open. We recommend using a Dremel or oscillating cutting tool for precision.
Carefully cut around the factory seal.
Lift the lens off and set aside in a clean area.
Step 4: Install your LED Product into your headlights.
Step 5: Reseal your headlights (see video above) or click here for full guide.
Step 6: If you haven't already, wire your LED Product onto your car using the included wiring guide or see our general wiring guide.
RGBW Bluetooth LED Controller w/ DRL SmartSwitch — Wiring & Setup Guide
Flow Series Bluetooth Controller w/ DRL SmartSwitch - Install Guide
Additional installation videos
These earlier demonstrations may show a different controller revision. Use the current kit-specific wiring instructions above for your supplied hardware.
Source and installation help
Checked against 2014-2021 Jeep Grand Cherokee multicolor DRL Boards Install Guide in the RGB Halo Kits Help Center on October 22, 2026. Follow the instructions supplied with your exact kit if hardware versions differ.
