Installation guide for 2015-2017 Ford Raptor RGBW DRL Boards

Welcome to our comprehensive installation guide for the 2015-2017 Ford Raptor RGBW DRL Boards! Elevate the style and functionality of your Raptor with these dynamic RGBW DRL boards. Follow our step-by-step instructions for a seamless installation process, ensuring your truck stands out with vibrant lighting effects while enhancing visibility on and off the road.


Product Link:

2015-2017 Ford Raptor RGBW DRL Boards – RGB Halo Kits

Install Guide:

Step 1: Test your Product. This ensures no manufacturing defects are in the LEDS, and that you understand how to wire your product properly. See the wiring guide that comes with your product or visit our wiring guide.

Step 2: Remove your bumper to access headlights.

2015-17 Ford F150 | 2017-20 F150 Raptor Bumper and Headlight Removal Guide PDF

Step 3:  Open your headlights. (*Headlights can be safely opened and resealed using the process outlined in the video below)

Step 4: Install your LED Product into your headlights.

We are currently in the process of creating a video installation guide for this product. In the meantime, if you need any assistance during the installation process, don't hesitate to reach out to us. We're here to help!

The following video is a Ford F150, not a raptor headlight; however, the process is relatively the same.

Step 5: Reseal your headlights (see video above) or click here for full guide

Step 6: If you haven't already, wire your LED Product onto your car using the included wiring guide.
