This installation reference covers 2020-2023 Chevrolet Silverado HD 2500/3500 RGBW DRL Boards. Match the product, vehicle configuration and controller part number before starting.
Product Link : 2020-2023 Chevrolet Silverado HD 2500/3500 RGBW DRL Boards
Step 1: Test your Product. This helps you check operation and confirm the wiring before permanent installation. See the wiring guide that comes with your product or (visit our Wiring Guide (RGBW and RGBWA)
Step 2: Remove your bumper to access headlights.
Step 3: Open your headlights. (*Confirm the opening and resealing method for your exact housing before following the video below)
Step 4: Install your LED Product into your headlights.
Step 5: Reseal your headlights (see video above) or click here for full guide.
Step 6: If you haven't already, wire your LED Product onto your car using the included Wiring Guide.
Additional installation videos
These earlier demonstrations may show a different controller revision. Use the current kit-specific wiring instructions above for your supplied hardware.
Source and installation help
Checked against Chevrolet Silverado HD 2500/3500 RGBW DRL Boards (2020-2023) Install Guide in the RGB Halo Kits Help Center on October 22, 2026. Follow the instructions supplied with your exact kit if hardware versions differ.
